| Empfohlene Platzierung |
Computergehäuse |
Lüfterdurchmesser |
12 cm |
Unterstützte Prozessorsteckplätze |
LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1366 (Socket B), LGA 1700, LGA 2011 (Socket R), LGA 2066, LGA 775 (Socket T) |
| Produkt- oder Artikelinformationsblatt verfügbar? |
Ja |
Kompatible Prozessoren |
Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9 |
Rotationsgeschwindigkeit (min.) |
900 RPM |
| Rotationsgeschwindigkeit (max.) |
2750 RPM |
Unterstützung der Pulsweitenmodulation |
Ja |
Pumpenanschluss |
3-polig |
| Menge pro Packung |
1 Stück(e) |
Motorschnelligkeit der Pumpe (min) |
2250 RPM |
Motorschnelligkeit der Pumpe (max) |
2750 RPM |
| Ventilatoren Geschwindigkeit (min) |
900 RPM |
Ventilatoren Geschwindigkeit (max) |
1800 RPM |
Kompatible Produkte |
Compatibilidad con Intel: LGA 775 / 1200 / 1151 / 1150 / 1155 / 1156 / 1366 / 1700 / 2011 / 2066
Compatibilidad con AMD: AM4 / AM5 |
| Produktfarbe |
Schwarz |
Heizkörpermaterial |
Aluminium |
Grundkörper Material |
Kupfer |
| Anzahl Lüfter |
2 Lüfter |
Beleuchtungs-LED |
Ja |
Farben der Beleuchtung |
Multi |
| LED-Anschlusstyp |
3-polig |
Ventilator-Anschluss |
4-polig |
Wasserblockmaterial |
Kupfer |
| Zertifizierung |
This symbol indicates that electrical appliances should not be discarded with other household waste. Used equipment sho- uld be handed over to a local collection point for this type of waste or to a recycling center. Please contact your local authorities for information about disposal methods available in your area. Wa- ste electrical equipment may contain hazardous substances (e.g.
mercury, lead, cadmium, chromium, phthaltes) which can get
into air, soil and groundwater when leaking from used appliances.
Environmental pollution with these substances leads to their bio- accumulation, causing lesion of disease in living organisms, which
would pose a risk to human and animal health or life. Households
may contribute to environmental protecion by proper waste collection. In such way, hazardous substances from the equipment
are neutralized and valuable secondary raw materials are reused
for production of new equipment. |
SATA Anschlüsse |
1 |
Thermal Design Power (TDP) |
250 W |
| Schlauch-/Rohrlänge |
40 cm |
Pumpenbreite |
15 cm |
Verpackungsbreite |
20 mm |
| Verpackungstiefe |
15 mm |
Verpackungshöhe |
35 mm |
Paketgewicht |
1,97 kg |
| Technische Eigenschaften |
Technical specification:
• TDP: 250 W
• Cooling standard: 240 mm
• Radiator dimensions: 277 × 120 × 27 mm
• Cooling pipes length: 400 mm
• Heat sink material: Aluminium
• Water block base material: Copper
• Number of fans: 2 × 120 mm
• Fan power connector: 4-pin (PWM) (male + female)
• Fan LED connector: 3-pin (male + female)
• Pump power connectors: 3-pin
• Pump LED connector: 3-pin (male + female)
• Fan speed: 900 - 1800 RPM • Pump speed: 2250 - 2750 RPM
• Intel compatibility: LGA 775 / 1200 / 1151 / 1150 / 1155 / 1156 / 1366 / 1700 / 2011 / 2066
• AMD compatibility: AM4 / AM5
• Set contents: Radiator with pump, 2 × 120 mm fans, mounting
accessories, thermal paste, user manual |
Garantiezeit |
2 Jahr(e) |
Konformitätsbescheinigungen |
CE |
| Sicherheitswarnung |
Safety conditions for heat sink and fan
• Use the product in accordance with its intended use, as im- proper use may damage the product.
• Do not expose the device to moisture. • The device should be cleaned only with a dry cloth. • Independent repairs and modification result automatic loss
of the warranty.
• Hitting or dropping may damage the product. |
Konformität von Elektro- und Elektronik-Altgeräten (WEEE) |
Ja |
Mitgelieferte Kabel |
3-polig, 4-polig, SATA |
| Montageset |
Ja |
Schrauben enthalten |
Ja |
Anzahl von Schrauben |
16 |
| Wärmepad enthalten |
Nein |
Fernbedienung enthalten |
Nein |
RGB-Controller enthalten |
Ja |
| Betriebsanleitung |
Ja |
Installationsanweisung |
Ja |
Adapterrahmen enthalten |
Ja |
| Ursprungsland |
China |
Typ |
Flüssigkeitskühlung |
Material |
Aluminium |
| Breite |
205 mm |
Höhe |
450 mm |
Gewicht |
1,53 kg |
